WJ Cast Iron Accessible Feed Check Valve
₹0.00
Enhance your boiler’s efficiency and reliability with the WJ Cast Iron Accessible Feed Check Valve. Designed for robust performance, this valve is ideal for industrial applications requiring high durability and precise control.
Superior Construction
Crafted with a sturdy outside screw yoke type and a rising spindle, the WJ Accessible Feed Check Valve ensures seamless operation under demanding conditions. The SS (AISI-410) seat and spindle provide excellent corrosion resistance, while the bolted bonnet and flanges conform to BS-10 Table ‘H’, guaranteeing secure and leak-proof connections.
Exceptional Performance
Built to handle a maximum working pressure of 185 PSIG (13 Kg/Cmg) and temperatures up to 428°F (220°C), this valve is also temperature tested to 370 PSIG (26 Kg/Cmg) Hydraulic Pressure. Its robust design makes it suitable for a wide range of industrial applications, ensuring long-lasting performance and safety.
Salient Features
- Dual Valve System: Incorporates a stop valve operated by a hand wheel and a back pressure check valve for enhanced control and reliability.
- Flexible Inlet Options: Available with either straight or curved inlets to suit various installation requirements.
- Easy Maintenance: The check valve’s accessibility allows for inspection during boiler operation by simply closing the stop valve and removing the inlet.
- Multiple Sizes: Available in 40mm, 50mm, and 65mm sizes, each with an inspection branch for added convenience.
Testing and Certification
Every WJ Cast Iron Accessible Feed Check Valve undergoes rigorous testing at double the maximum working pressure to ensure safety and reliability. Each unit is accompanied by an IBR Test Certificate in Form III-C, issued by The Director of Boilers, Punjab, guaranteeing compliance with industry standards.
Why Choose V.S. Machinery & Spares?
Located in Delhi, V.S. Machinery & Spares is your trusted partner for WJ IBR Valves and a wide range of industrial components including pressure switches, solenoid valves, temperature gauges, boiler mountings, and process control instruments. With over 50 years of experience, we pride ourselves on delivering 100% customer satisfaction to industries across India.
Get your WJ Cast Iron Accessible Feed Check Valve today! Tap the “Get Quote Via WhatsApp” button on this product page for a quick and hassle-free quote.
