WJ cast iron Spring Loaded Single Post Safety Valve
₹0.00
Ensure the utmost safety and efficiency in your industrial systems with the WJ Cast Iron Spring Loaded Single Post Safety Valve. Meticulously designed and constructed, this safety valve is your reliable partner in maintaining optimal pressure levels and safeguarding your equipment.
Premium Material and Construction
- Durable Build: Crafted from robust cast iron, the valve body ensures long-lasting performance and resistance to harsh industrial environments.
- High-Quality Components: Equipped with a 13% Chromium Stainless Steel (AISI-410) seat and stem, providing excellent corrosion resistance and durability.
- Full Lift Mechanism: Designed for an instantaneous full lift of the seat, allowing rapid pressure release to prevent system overpressure.
Precision Engineering
- Flange Specifications:
- Inlet Flange: Conforms to BS-10 Table ‘H’ for seamless integration.
- Outlet Flange: Sized according to BS-10 Table ‘D’, larger than the inlet flange to ensure efficient discharge.
- Pressure Rating: Engineered to operate at a maximum pressure of 13 Kg/Cm² (185 PSIG), offering reliable protection against overpressure scenarios.
Salient Features
- Instantaneous Full Lift: Ensures immediate response to pressure spikes, maintaining system integrity.
- Optimized Flange Sizes: Larger outlet flange enhances discharge efficiency.
- Easing Lever: Facilitates easy manual operation and adjustments.
- Security Lock: Prevents unauthorized pressure adjustments by concealing the adjusting screw with a cast iron cap and locking the easing lever with a pin.
Testing and Certification
- Rigorous Testing: Each valve is tested under 26 Kg/Cm² (370 PSIG) hydraulic pressure to ensure robustness and reliability.
- Operational Setting: Valves are preset to release at a maximum pressure of 13 Kg/Cm² (185 PSIG) under steam conditions.
- Certified Quality: Comes with an IBR Test Certificate in Form Ill-C, issued by The Director of Boilers, Punjab, ensuring compliance with industry standards.
